Brass oil level sight glass

GrandMfg® Hexagon brass Oil level sight glass plugs Ölschauglas NPT Thread

Hexagon brass Oil sight glass(BSP&Meteric thread)
Body: brass HPb57-3
Glass:Tempered Glass 2mm to 8mm
Seal: NBR,VITON.Armaid,Teflon
Reflector: brass,aluminum,304 stainless steel
Thread: BSP thread(G thread) and Metirc
Working temperature:
Working pressure: 0.1MPa to 10MPa(1bar to 10bar)
INQUIRY

SPEED REDUCERS BRASS OIL LEVEL SIGHT GLASS INDICATOR SUPPLIER & MANUFACTURER

NPT AND BSP THREAD 1/2" 3/8" 3/4" 1" 1-1/4" 2" HEX OIL SIGHT GLASS SUPPLIED

item	brass sight glasses
material	brass
O-Ring	Viton,FKM,NBR, Aramid gasket and Copper seal
window	Natural Glass,Tempered Glass and Borosilicate Glass
Glass Thickness	2mm to 5 mm
Reflectors	Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.)
Resist Tempreature Range	.-30'C TO 120'C
Pressure Range	5-10 Bar(0.5MPa to 1 MPa).
Thread type	NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

GrandMfg® Brass Oil level sight glass plugs

Material Body: Brass

O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal

Glass Thickness: 2mm to 5 mm

Reflectors: Stainless Steel 304 Reflector

(Any type you can chose with reflector or without Reflector, You also can add float ball.)

Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass

Resist Tempreature Range:-30'C to 120'C

Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).

Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)

Size： Below you will get the size you wanted.Another size is okay.OEM are welcome.

Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.
